Description
Features:
1. Photoelectric sensor, automatic blowing.
2. Adopt with circulation wind to ensure the cleanness of shower area under non-shower status.
3. Double doors by electric interlock.
4. LED display with adjustable blowing time(0~99s).
5. HEPA filter, Class 100 cleanness.
Technical Parameters:
|
Model |
AS-1P1S |
AS-1P2S |
AS-2P2S |
|
External Size(W*D*H) |
1300*1000*2050mm |
1500*1000*2050mm |
1500*2000*2050mm |
|
Shower Area Size(W*D*H) |
800*900*1930mm |
800*900*1930mm |
800*1900*1930mm |
|
HEPA Filter |
99.995% efficiency at 0.3μm |
||
|
Spraying Wind Speed |
25m/s |
||
|
Air Shower Time |
0~99s(adjustable) |
||
|
No.of SS Nozzles |
6 |
12 |
24 |
|
Fluorescent Lamp |
12W*1 |
12W*1 |
12W*1 |
|
Consumption |
550W |
1100W |
2200W |
|
Cabinet Material(Optional) |
1. Full cold-rolled steel with powder coating. 2. Internal stainless steel, external with cold-rolled steel. 3. Full stainless steel. |
||
|
Door Material(Optional) |
1. Cold-rolled steel with powder coating. 2. Stainless steel. |
||
|
Chassis |
Stainless steel |
||
|
Power Supply |
AC220V±10%, 50/60Hz; 110V±10%, 60Hz |
||
|
Gross Weight |
300kg |
400kg |
700kg |
|
Package Size(W*D*H)mm |
1400*1200*2200 |
1600*1200*2200 |
1600*2200*2200 |
