Auto ELISA Processor 2001

Auto ELISA Processor AP Medical2001 Features: 1. Adopt the principle of pressure type liquid detection. 2. With TIP detection, clot detection function. 3. High-precision pipetting. 4. Position sensing, real-time monitoring of gripper status. 5. Multi-spacing and multi-strength adjustable grippers can be adapted to grasp and place microplates and plate covers of different sizes. 6. Dual thread control, can run simultaneously with the sampling arm without interfering with each other. Technical Parameters: Model AP Medical2001 Sample&Reagent Unit Sample Racks 6*20 push-pull sample rack with detection Sample Channel 2 channels Liquid Level Detection Air pressure level detection, clot detection function Tip 1000μl, 3 tip racks Pipetting 10μl~1000μl Pipetting Precision 100μl: CV≤1%, Accuracy≤2.5% 1000μl: CV≤0.5%, Accuracy≤1% Reagent Position 4 reagent racks, reagent tanks with detection Washing Unit Washer 1 unit Washing Head 16-channel(32-pin), double row cleaning, hanging installation, with leakage recovery Injection Uniformity CV<1.5% Washing Residual <1μl Reading Unit Reading Channels 8 independent photometric channels Linear Range 0.000~3.000Abs Repeatability CV≤1.0% Stability ≤±0.003Abs Optical Filters 4 standard filters(405, 450, 492, 630nm); Total 10 filters positions Reading Accuracy ≤±0.02Abs from 0.0 to 1.0OD ≤±0.03Abs from 1.0 to 2.0OD Sensitivity ≥0.01mg/L Channel Difference ≤0.02Abs Incubation Unit Incubators 8 shaking incubators Cover Positions 1(8 covers) Heating Method Dry heating with cover Shaking Function Horizontal circular oscillation, 1~3 levels adjustable, amplitude 2.5mm Temperature Range RT to 60 °C Temperature Uniformity 0.5℃ Temperature Fluctuation ±0.5℃ Data Management Software Above Windows 7 system LIS System Bi-direction, support HL7 protocol Results Absorbance and results reviewable by software Printer External optional Built-in Scanner Optional Other Function Biosafety Protection Optional (Negative pressure working zone, HEPA filter) Disinfection UV lamp Lighting LED IAP Function Firmware can be upgraded online at any time Working Condition Power Supply AC220V±10%, 50/60Hz(Standard); 110V±10%, 60Hz( Optional) Temperature 10~40℃ Humidity 30~80% Size&Weight External Size(W*D*H) Machine: 1273*750*1650mm Base Stand: 1273*750*777mm Net Weight Machine: 226kg Base Stand: 98kg Package Size(W*D*H)mm Machine: 1445*920*1130mm Base Stand: 1445*920*1005mm Accessories: 1065*895*510mm Gross Weight(kg) Machine: 300kg Base Stand: 172kg Accessories: 83kg
