Description
Features:
1. Different batches and the same batch cleaning point cleaning effect is the same.
2. Realize the traceability management of cleaning data.
3. 7 inch color LCD touch screen, easy to operate.
4. Equipped with preheating water tank to reduce water heating preparation time.
5. The fast cleaning program can be cleaned once in 4~6 minutes to meet the fast cleaning.
6. Up to 40 mouse IVC cages can be cleaned at a time.
7. Through automatic program control of cleaning process and monitoring of key parameters, to achieve automated and standardized cleaning.
Technical Parameters:
|
Model |
BKCW-1500 |
BKCW-1500Z |
||
|
Capacity(L) |
1500 |
|||
|
Cleaning Volume |
Up to 40 mouse IVC cages can be cleaned |
|||
|
Opening Mode |
Automatic |
|||
|
Control System |
PLC/Siemens |
|||
|
Touch Screen |
7 Inch |
|||
|
Cleaning Time |
Quick cleaning program can be cleaned once in 4~6 minutes |
|||
|
Cleaning Temperature |
＞60°C(Adjustable) |
|||
|
Rinsing Temperature |
＞82°C(Adjustable) |
|||
|
Drying Temperature |
RT~120℃(Optional) |
|||
|
Heating Method |
Electric Heating |
Steam Heating |
||
|
Steam Source |
/ |
Pressure: 0.3~0.5Mpa, Flow Rate: 50kg/h |
||
|
Water Source |
Softened Water: Pressure: 0.2~0.5Mpa, Flow Rate: 25L/min |
|||
|
Compressed Air Source |
Pressure: 0.5~0.7Mpa, Flow Rate: 100L/min |
|||
|
Consumption |
34KW |
4KW |
||
|
Power Supply |
AC380V, 50Hz; 220V, 50Hz |
AC380V, 50Hz; 220V, 50Hz |
||
|
Power Supply(Optional) |
AC220V, 60Hz; 220V, 60Hz(Three phase); 380V, 60Hz; 110V, 50/60Hz |
|||
|
External Size(W*D*H) |
2140*925*1950mm |
|||
|
Net Weight |
420kg |
|||
|
Package Size(W*D*H) |
2250*1050*2160mm |
|||
|
Gross Weight |
500kg |
|||
