BKN-986 Kjeldahl Apparatus Kjeldahl Nitrogen Analyzer

Description

BKN-986 Kjeldahl Apparatus Kjeldahl Nitrogen Analyzer

Introduction：

Built in colorimetric titration device; Two steam models, can adjust solutions adding’s sequence, for distillation and absorption special samples; Touch screen used for operating and display.

Technical Parameters:

Model

BKN-984

BKN-110F

BKN-986

Water Consumption

1.5L/Min

Steam Generator Water Consumption： 2.4L/H

Ambient Temperature

5~40℃

Ambient Humidity

80%

Measure Range

0.1mg~240mg

Analysis Time

3~6min

5~10min

Recovery Ratio

≥99.5%

Sample Amount

Solid ≤6g;

Liquid ≤16ml

Solid ≤ 5g;

Liquid ≤20ml

Burette Accuracy

/

1.0μL/ step

2μL/ step

Reproducibility

/

±0.5%

±0.5%

Consumption

2000W

Power Supply

AC110/220 V ±10%,60/50Hz

Packing size(W*D*H)

655*528*880mm

Main body:585*525*900mm

Accessories:605*600*355mm

Main body:585*525*905mm

Accessories:600*600*360mm

Gross weight

45Kg

Main body:52.7kg,

Accessories:12.5kg

 Main body:50.3Kg,

Accessories:13.4kg

Functions List

BKN-984

BKN-110F

BKN-986

Variable Steam Generator

●

●

●

Cooling Water Pressure Monitor

●

●

●

Cooling Water Temperature Monitor

●

●

Automatic Alkali Solution Adding

●

●

●

Automatic Dilute Water

●

●

●

Auto Solution Adding

●

●

●

Tube Emptying

●

●

●

Removable Drain Tray

●

●

●

Safety Door

●

●

●

Tube on Position Sensor

●

●

Tube Replacement Sensor

●

●

Colorimetric Titration Device

●

●

Result Calculation

●

●

Result and Data Storing

●

●

Built-in Printer

●

Automatic fault detection function

●

●

●

Titration While Distillation

●
