Description
UV air sterilizer is a kind of equipment which is composed of ultraviolet lamp, filter, fan and ballast, mainly used for air disinfection. The working principle is that part of the dirty air in the closed room is sucked into the machine through the ultra-static fan, the dust is filtered through the composite filter, and then the bacteria in the flowing air is instantly killed by the ultraviolet lamp, and finally the clean air that has been filtered out of the dust and killed bacteria is sent back to the room to achieve the purpose of air purification and sterilization.
Product Features
- Designed for use in both manned and unmanned environments, ensuring versatile disinfection capabilities.
- Equipped with an LED display showing total running time for 20 seconds after shutdown for easy monitoring.
- Offers dual wind direction control: manual adjustment of wind angle for precise airflow management.
- Controlled by a single-chip microcomputer core, allowing scheduling of three switch segments within 24 hours.
- Adjustable wind speed with three available APM to suit different disinfection needs.
- Supports three working modes: manual, scheduled, and temporary, providing flexible operation options.
- Easy-to-remove filter design facilitates convenient maintenance and replacement.
Technical Specifications: BKS-B-600
| Parameter | Specification |
|---|---|
| Applicable Space | Up to 60 m³ |
| Circulating Air Volume | ≥ 600 m³/h |
| Shell Material | ABS with anti-UV properties |
| Filter | Activated carbon; filters dust particles ≥ 5μm |
| UV Lamp Life | ≥ 5000 hours |
| UV Leakage | ≤ 3 μW/cm² |
| Ozone (O₃) Leakage | ≤ 0.006 mg/cm³ |
| Negative Ion Generation | ≥ 5 × 10⁶ PCS/cm³ |
| Natural Bacteria Extinction Rate | ≥ 90% |
| Sterilization Rate (Staphylococcus Albus) | ≥ 99.9% |
| Noise Level | ≤ 55 dB(A) |
| Power Consumption | ≤ 130 W |
| Power Supply | AC220V, 50/60Hz (Standard); AC110V, 50/60Hz (Optional, via external transformer) |
| Dimensions (W×D×H) | 885 × 280 × 220 mm |
| Net Weight | 7.2 kg |
| Package Dimensions (W×D×H) | 1100 × 280 × 385 mm |
| Gross Weight | 9.8 kg |
Product relationship
Applied Physics OEM Medical
This is Applied Physics-branded OEM medical or laboratory equipment, contract manufactured for Applied Physics. Applied Physics provides product selection, quotation and customer support.
Applied Physics portfolio: Medical
Disinfection-system quote checklist
Confirm load or room application, material compatibility, capacity, process objective, exposure/cycle requirement, ventilation constraints, utilities and site-specific documentation requirements.
