Description
Application: It is suitable for the detection of prothrombin time(PT), activated partial thromboplastin time(APTT), thrombin time(TT) and fibrinogen(FIB) in plasma. . Widely used in blood laboratory, biochemical laboratory, hospital blood laboratory and so on. Features: 1. Dual-channel independent detection, can analyze different items at the same time. 2. 5-inch high-definition touch screen, easy to operate. 3. Open system, good compatibility, Supports reagents of various specifications. 4. 20,000 results storage. 5. Equipped with multiple pre-temperature positions to improve detection efficiency. 6. Built-in thermal printer. 7. The pipette automatically triggers the measurement, and the measurement time can be accurate to tenths of a second. 8. Less reagent consumption. Technical Parameters:
| Model | BK-CA02 | BK-CA04 |
| Test Principle | Optical colorimetry | |
| Test Items | PT, APTT, TT, FIB | |
| Test Channel | 2(can test different projects at the same time) | 4(can test different projects at the same time) |
| Wavelength | 470nm | |
| Detection Time | Normal sample detection time is 20 to 40 seconds, and can be set arbitrarily from 20 to 99 seconds | |
| Sample Incubation Position | 12 | 24 |
| Reagent Incubation Position | 5 | 6 |
| Detection Position Temperature | 37.0±1.0°C | |
| Incubation Position Temperature | 37.0±1.0°C | |
| Incubation Time | 1~999s | |
| Reaction Time | 1~99s | |
| Reagent Dosage | Minimum dosage 20μl | |
| Sample Volume | 20μl~40μl | |
| Display | 7-inch high-definition color touch screen | |
| Storage | 200,000 results storage, automatically save measurement data when power off | |
| Communication Interface | RS232 serial interface, support LIS system | |
| Printer | Built-in thermal printer | |
| Power Supply | AC100~240V, 50/60Hz | |
| Consumption | 70VA | |
| Ambient Temperature | 10℃~30℃ | |
| Relative Humidity | ≤80% | |
| Atmospheric Pressure | 86kPa~106kPa | |
| External Size(W*D*H) | 360*210*120mm | 390*250*135mm |
| Net Weight | 3.5kg | 4.96kg |
| Package Size(W*D*H) | 376*246*316mm | 445*305*265mm |
| Gross Weight | 5kg | 7kg |
