Description
Features: 1. Microcomputer control is adopted to realize the integration of weighing and collecting liquid. 2. Built-in large capacity lithium battery, long battery life. 3. With automatic sound and light alarm function, when the amount of liquid reaches the predetermined value or the predetermined time, the alarm prompts. 4. The gentle swing mode is safer for platelets and red blood cells that are easily damaged in the blood. 5. Using new type of weighing sensor, weighing more accurate. 6. Constant speed motor, low noise, long service life. 7. The liquid collection digital display is displayed in milliliters without calculation and conversion, which is more convenient and convenient to use. Technical Parameters:
| Model | BCM-4 | BCM-12Z |
| Measuring Range | 0~1200ml | 0~1200ml |
| Display | LED | 3.5-inch color LCD touch screen |
| Resolution | 1ml | |
| Liquid Proportion | 1.05g/ml | |
| Collection Speed | 0.5~3ml/s | |
| Static Error | ±2g | |
| Swing Angle | 13±2° | |
| Swing Frequency | 30±2r/min | |
| Alarm | Collection finish, Automatic sound and light dual alarm | Collection finish, Automatic sound and light dual alarm, Clamp obstruction |
| Obstruct Pipeline | / | Outer diameter φ3~φ6mm, wall thickness: 0.5mm |
| Obstruct Resistance | / | ＜14N |
| Ambient Temperature | 5℃~40℃ | |
| Battery | Lithium battery, 12V, 5000mAh, 3 hours of battery life | / |
| Consumption | 17W | 30W |
| Power Supply | 100~240V, 50/60Hz | |
| External Size(W*D*H) | 190*240*165mm | 285*240*190mm |
| Net Weight | 2.5kg | 3.5kg |
| Packing Size(W*D*H) | 380*260*290mm | |
| Gross Weight | 3.5kg | 5.5kg |
