Description
Features: 1. Programmable microprocessor control(AC brushless motor). 2. LCD& LED display: speed, RCF, time and temperature, conversion of RPM/RCF. 3. CFC-free refrigeration, fast cooling, cycle defrost system. 4. External cold rolled steel with powder coating steel, stainless steel centrifugal chamber and lid. 5. Fan-forced air circulation system for fast recovery of temperature. 6. 10 procedures of adjustable speed from grad 0 to 9 and 40 kinds of self-defining modes. 7. Electronic lock lid and interlock safety system. 8. Alarm: lid open, imbalance, over speed, over temperature, rotor mounting abnormally. 9. Function: RCF selection, quick run, automatic rotor recognition and backup, electronic Imbalance detection, dynamic electric brake system. Technical Parameters:
 Model | BKC-TL5RL | BKC-VL6RLII |
| Max. Capacity | 4*750ml | 6*1000ml |
| Max. Speed | 5500rpm | 6000rpm |
| Max. RCF | 4390xg | 6680xg |
| Speed Precision | ±30rpm | ±20rpm |
| Temp. Range | -20~40°C | |
| Temp. Accuracy | ±1°C | |
| Timing Range | 0~99h59min59s | 0~99h59min59s |
| Noise | ≤60dB | ≤58dB |
| Consumption | 1.2KW | 3KW |
| Power Supply | AC220±22V 50/60Hz (Standard); AC110V 60Hz (Optional) | |
| External Size(W*D*H) mm | 703*710*400 | 725*940*970 |
| Packing Size(W*D*H) mm | 910*825*570 | 870*1040*1380 |
| Net Weight(kg) | 110 | 280 |
| Gross Weight(kg) | 130 | 330 |
Rotor for BKC-TL5RL:
| No. | Rotor | Max. Speed(rpm) | RCF (xg) | capacity | Dimension of Tube (mm) |
| NO.1 | Angle Rotor | 5500 | 4390 | 12*10ml | Φ16*83 |
| NO.2 | Angle Rotor | 5500 | 4390 | 12*15ml | Φ17*121 |
| NO.3 | Swing Rotor | / | / | Support | / |
| Tube Rack | 4000 | 2810 | 4*100ml | Φ38*116 | |
| 4*2*100ml | Φ38*116 | ||||
| 4*4*10ml | Φ16*106 | ||||
| 4*6*10ml | Φ16*106 | ||||
| 4*8*10ml | Φ16*106 | ||||
| 4*4*15ml(▲/●) | Φ16*120 | ||||
| 4*6*15ml(▲/●) | Φ16*120 | ||||
| 4*8*15ml(▲/●) | Φ16*120 | ||||
| 4*50ml(▲/●) | Φ29*116 | ||||
| 4*2*50ml(▲/●) | Φ29*116 | ||||
| NO.4 | Swing Rotor | 4200 | 3500 | 4*250ml | Φ62*126 |
| Adapter | 4200 | 3500 | 4*8*5ml | / | |
| 4*8*7ml | / | ||||
| 4*7*10ml | / | ||||
| 4*6*15ml | / | ||||
| 4*2*50ml(●) | / | ||||
| 4*1*50ml(▲) | / | ||||
| 4*100ml | / | ||||
| NO.5 | Swing Rotor | 4000 | 3040 | 4*500ml | Φ80*137 |
| Adapter | 4000 | 3040 | 4*15*5ml | / | |
| 4*15*7ml | / | ||||
| 4*12*10ml | / | ||||
| 4*8*15ml(▲) | / | ||||
| 4*4*50ml(▲/●) | / | ||||
| 4*2*100ml | / | ||||
| 4*250ml | / | ||||
| NO.6 | Swing Rotor | 4000 | 3180 | 4*750ml | Φ99*137 |
| NO.7 | Swing Rotor | 4200 | 3500 | 4*12*7/5ml | Φ13*110/90 |
| NO.8 | Swing Rotor | 4200 | 3500 | 4*18*7/5ml | Φ13*110/90 |
| NO.9 | Swing Rotor | 4000 | 3040 | 4*24*7/5ml | Φ13*110/90 |
| NO.10 | Microplate Rotor | 4000 | 2000 | 2*2*48well | Microplate |
| NO.11 | Microplate Rotor | 4200 | 2360 | 2*2*96well | Microplate |
Rotor for BKC-VL6RLII：
| No. | Rotor | Max. Speed(rpm) | RCF(xg) | Capacity | Dimension of Bottle (mm) |
| No.1 | Angle Rotor | 6000 | 5650 | 6*300ml | Φ63*157 |
| No.2 | Angle Rotor | 6000 | 6680 | 6*500ml | Φ74*168 |
| No.3 | Swing Rotor (round cup) | 4200 | 5030 | 6*1000ml | Φ100*175 |
| No.4 | Swing Rotor (square cup) | 4200 | 5030 | 6*1000ml | / |
