Micro-Volume UV/VIS Spectrophotometer

Description

Micro-Volume UV/VIS Spectrophotometer

Features:

1. Most samples don’t need dilute.

2. Microscale sample test, minimum 0.5μI.

3. PC control, more accurate and flexible.

4. Ultromicro and cuvette dual platform(Only for BK-CW2000).

5. Wide test area, 100 times of the traditional spectrophotometer.

6. Test directly without warming up, do not need detection container, lower daily consumption.

Technical Parameters:

Model

BK-CW1000

BK-CW2000

Minimum Sample Capacity

0.5μl

Ultromicro Optical Distance

1mm/0.2mm

1mm/0.2mm/0.05mm

Cuvette Optical Distance

/

10mm/5mm/2mm/1mm

Whole Wavelength

190~1100nm

Scanning Wavelength

190~850nm

Wavelength Accuracy

1nm

Wavelength Resolution

≤0.3nm([email protected])

Absorbance Accuracy

2%(0.76@257nm)

Absorbance Resolution

0.002Abs(1mm)

Absorbance Range

0.02~300(10mm)

0.005~300(10mm)

Test Accuracy

0.1~5 Abs.±0.1 Abs 5~80 Abs.±2%

0.01~0.5 Abs.±0.01Abs 0.5~80 Abs. ±2%

Test Time

5s

Detector

3648 pixel linear CCD array

Light Source

Xenon flash lamp

Sample Test Platform Material

304 stainless steel and quartz

Standard Accessories

• Driver software CD 1pc • Power line 1pc • Power Adapter 1pc

Consumption

24W

Power Supply

AC110/220V±10%, 50/60Hz

External Size(W*D*H)mm

200*130*136

Package Size(W*D*H)mm

310*310*310

Net Weight(kg)

2.5

Gross Weight(kg)

5
