| R2S Standard Sampler | Model# AP-R2S.002 |
| R2S Materials | Aluminum / 316 Stainless Steel |
| R2S Finish | White Epoxy/Polyester Coating |
| R2S Dome | Clear Polycarbonate / .007″ Slit Width |
| R2S Weight | 3 Pounds |
| R2S Dimensions | 5.5“Height X 5“ Diameter |
| R2S Media (suggested) | 100mm TSA (most vendors/suppliers) |
| R2S Part# | R2S.R2SSMP |
| R2S Description | R2S Standard Sampling Head |
Description
The R2S Remote Start model allows for placement of the controller unit up to 54′ from critical operations with Start/Stop/Timer Reset functions controlled from an “In-Line” switch housed in a NEMA 4X enclosure. The control switch can be placed in-line between the controller and the sampler head at a customer specified location. The R2S Remote Start model has a flow rate of 28.3 SLPM, or 60 SCFH or 1 CFM. It is an ideal sampling device for monitoring of your critical ISO 5 Rooms, Hoods and Isolators.
R2S REMOTE STAT SPECIFICATIONS
| R2S-C Remote Start Controller | Model# AP-R2S-C.RMTCNT |
| R2S-C Instrument Case | Aluminum |
| R2S-C Finish | Blue/White Powder Coat |
| R2S-C Dimensions | 15“ x 8“ x 9“ |
| R2S-C Weight | 23 Lbs |
| Remote Start Sample Timer | 0‘1“ to 59‘59“ User Defined/Set |
| Sample Rate | 60 SCFH (28.3 SLPM / 1 CFM) |
| Sample Volume | 60 Cubic Feet (1698L)/Hour/Test Plate |
| HEPA Filtered Exhaust | 0.2 Micron, >99.97% Efficiency |
| Operating Voltage | 115 VAC@ 60 Hz |
| Primary Power Cord | 10 Feet with In-Line GFI Protection |
| R2S Power/Vacuum Supply | 6‘ or 12‘ Standard 3-Pin/5-Pin Cables |
| Remote Start/Stop/Reset Switch | In-Line NEMA 4X Enclosure w/Momentary Start/Stop/Reset Pushbutton |
| Sampler Package Description | R2S Remote Start Sampler Package |
| Sampler Package Part# | AP-R2S.RMTPAK |
System may use up to 54′ of vacuum tubing (Purchased Separately)
