Description
Features:
1. High quality stainless steel sterilization chamber and sealing cover.
2. Microcomputer control for automatic circulation, with 121°C and 134°C freely settable.
3. LED display with touch buttons.
4. Equipped with standard test interface.
5. European Class N standards.
6. Automatic protection functions: over-temperature protection, over-pressure protection, low water level protection to prevent dry burning.
7. Buzzer reminder at the end of sterilization and automatic shutdown.
8. Automatically discharge cold air. Automatically discharge steam at the end of sterilization.
9. Built-in steam generating device to quickly provide saturated steam.
10. Two sterilization procedures at 121°C and 134°C are selectable.
Technical Parameters:
|
Model |
BKX-T18E |
BKX-T23E |
|
Capacity |
18L |
23L |
|
Door |
Manual |
|
|
Display |
LED |
|
|
Max Designed Pressure |
0.25MPa |
|
|
Working Pressure |
0.22MPa |
|
|
Max Design Temp. |
139℃ |
|
|
Working Temp. |
121/134℃ |
|
|
Temp. Precision |
0.1℃ |
|
|
Chamber Material |
SUS304 |
|
|
Chamber Size |
φ250*370mm |
φ250*452mm |
| Altitude | ≤2500m | |
| Rack | 1 rack with 2 trays | |
| Standard Accessories | Protective gloves, draining hose, door seal | |
| Consumption | 1.5KW | 2KW |
|
Power Supply |
AC220V, 50Hz(Standard) AC110V, 60Hz(Optional) |
|
|
External Size(W*D*H) |
500*400*350mm |
600*400*350mm |
| Net Weight | 24kg | 27kg |
|
Package Size(W*D*H) |
540*450*390mm |
640*450*390mm |
| Gross Weight |
26kg |
29kg |
