Tissue embedding machine ‌ is a kind of equipment used in biomedical laboratories, mainly used for tissue sample embedding process. Embedding is an important step in histology and pathology to fix a biological tissue sample in a suitable medium for subsequent sectioning and microscopic observation.

SKU: AP-PATH-EMB-GEN Categories: Catalog relationship: Available Through Applied Physics
Related Applied Physics resources

Continue through the Medical portfolio

Use these technical and portfolio pages to compare applications and related equipment. To keep this exact product attached to an RFQ, use the product’s existing Request a Quote or Add To Order control.

Description

Features:

1. Fully automatic program control, can be preset to start any day within a week

2. The temperature control adopts a single-chip microprocessor controller, and the temperature setting is simple

3. Using a new type of heating element, the heating is fast, the heating is uniform, and the energy saving is reliable.

4. Equipped with a small cooling platform, the base mold paraffin can be quickly pre-cooled.



Technical Parameters:

Model

BK-TEI

Thermal Temperature Range

RT~80℃

Control Temperature Precision

±3℃

Timing Range

0~24h

Paraffin Chamber Size

350*145*80mm

Thermal Storage Size

205*145*60mm, two pcs

Working Area Size

500*145mm

Power

1100W

Power Supply

AC220V,50/60Hz(Standard);

AC110V, 60Hz(Optional)

External Size(W*D*H)

525*550*500mm

Net Weight

36kg

Packing Size(W*D*H)

650*660*660mm

Gross Weight

43kg
