Description
Technical Parameters:
| Model | BJPX-SVO200 | BJPX-SV200 |
| Capacity | 200L | |
| Type | With ozone | Without ozone |
| UV Ray Wavelength | 253.7/184.9nm | 253.7nm |
| Sterilization Way | 2 sides of UV ray+1 side of ozone | 3 sides of UVC UV ray |
| UV Lamp Material | Quartz glass | |
| Altitude | ＜2000m | |
| Shelf | 500*520mm, standard 2pcs, can be optional | |
| Standard Accessories | Shelf*2,doorknob*1, UV lamp*4，Ozone UV lamp*2 | Shelf*2,doorknob*1, UV lamp*6 |
| Consumption | 120W | |
| Power Supply | AC220V, 50/60Hz(Standard); AC110V, 50/60Hz(Optional) | |
| Internal Size | 518*523*778mm | |
| External Size(W*D*H) | 750*663*1200mm | |
| Net Weight | 81kg | |
| Package Size(W*D*H) | 875*788*1365mm | |
| Gross Weight | 100kg | |
Recommended UV Exposure Time:
| Microorganism Species | Exposure Dose | Exposure Time |
| Bacterial Propagules | ≥10000μW.s/cm2 | 10min |
| Bacterial Spores | ≥100000μW.s/cm2 | 10min |
| Virus | 10000μW.s/cm2≤Exposure Dose≤100000μW.s/cm2 | 10min |
| Fungal Spores | General Exposure Dose≤100000μW.s/cm2 Special Exposure Dose up to 600000μW.s/cm2 | 60min |
| When the target microorganism is unknown | ≥100000μW.s/cm2 | 10min |
Remarks: The suitable temperature range for ultraviolet disinfection is 20℃~40℃. If the temperature is too high or too low, the disinfection effect will be affected, and the disinfection time can be appropriately extended.
Product relationship
Applied Physics OEM Medical
This is Applied Physics-branded OEM medical or laboratory equipment, contract manufactured for Applied Physics. Applied Physics provides product selection, quotation and customer support.
Applied Physics portfolio: Medical
Disinfection-system quote checklist
Confirm load or room application, material compatibility, capacity, process objective, exposure/cycle requirement, ventilation constraints, utilities and site-specific documentation requirements.
