Description
Features: 1. Structure: The chamber is made of mirrored stainless steel 2. Opening design: The equipment is equipped with a non-protruding overall arc door handle sheet metal design 3. Control system: 9 sets of operating modes are optional, and the control method of cyclic switching during the day and night 4. Humidification system: Adopts an external ultrasonic humidifier and a duct-type multi-point mist outlet humidification method to avoid the unevenness of a single mist outlet 5. Protection function: If the equipment is over-temperature or under-temperature or the sensor fails, the controller will alarm in time and display the alarm in text 6. CO₂ control: Adopts a special far-infrared CO₂ sensor, which has fast response, accurate concentration measurement and stable control Technical Parameters:
| Model | BJPX-CA500-B3 BJPX-CA500-C3 BJPX-CA500-D3 | BJPX-CA1000-B3 BJPX-CA1000-C3 BJPX-CA1000-D3 | BJPX-CA1500-B3 BJPX-CA1500-C3 BJPX-CA1500-D3 |
| Capacity | 500L | 1000L | 1500L |
| Temperature Control Range | 0-50℃(without light); 10-50℃(with light) | ||
| Temperature Resolution | 0.1℃ | ||
| Temperature Fluctuation | ±1℃ | ||
| Humidity Control Range | 50~99%RH(The humidity setting is effective when the temperature is above 10℃) | ||
| Humidity Fluctuation | ±3~±7%RH | ||
| Illumination | B3 type: 0~15000lux; C3 type: 0~20000lux; D3 type: 0~30000lux | ||
| Lighting Method | Top lighting LED light panel (400*400mm), monochromatic light | ||
| Light Panel | 3pcs | ||
| CO₂ Concentration Control Range | Atmosphere-6000PPM | ||
| Ambient Temperature | 10~30℃ | ||
| Inner Material | Stainless Steel | ||
| Outer Material | Cold-rolled sprayed steel plate | ||
| Timing Range | 0-99h59min/continuous | ||
| Power(W) | B3 type:1066; C3 type:1096; D3 type:1141 | B3 type:1842; C3 type:1902; D3 type:1992 | B3 type:3555; C3 type:3645; D3 type:3780 |
| Power Supply | 220V 50Hz | ||
| Optional Accessories | Printer, USB, UV lamp, timed ventilation function, test hole, inner door | ||
| Packing Size | 840*830*2020mm | 1360*870*1930 | 1860*830*2070 |
| Gross Weight | 180kg | 265kg | 320kg |
