Description
MOST COMPACT ULTRAPURE WHITE FOG CLEANROOM FOGGER IN MARKET WITH 20 STAINLESS STEEL HIGH PERFORMANCE STAINLESS STEEL TRANSDUCERS. ATOMIZING FROM 0.55 gal W/FAN SET TO 25 % LOAD) TO 1.32 gal W/FAN SET TO 100 % LOAD . CYCLE TIME @ 52 min AT MIXED SETTINGS . 40 min CYCLE TIME AT 100 % SETTINGS . COMPACT DIMENSIONS W/SQUARE FOOTPRINT OF 13.8 x 12.6 x 11.4 in AND LOW WEIGHT W/ONLY 30 lbs . COMPATIBLE WITH STANDARD ACCESSORY. ELIGIBLE FOR 2 YEAR EXTENDED WARRANTY
CRF2-S Decontaminating Fogger generates ≈ 0.26 cubic meters of visible sanitizing fog / minute, which evaporates and exponentially expands to cover ≈ 3,000 cubic feet per sanitizing cycle of 50 minutes. The CRf2-S uses a solution of hydrogen peroxide in purified water or distilled water to sanitize a closed area from unwanted bio-organisms, such as envelope viruses, bacterial growth, molds, spores, fungus and bio-organisms.
The CRF2-S is a portable, sanitizing fogger, using a solution of distilled water and H2O2, hydrogen peroxide to generate about 0.26 cubic meters of sanitizing fog per minute, which begins to evaporate about 6 feet distance, exponentially expanding to a sanitizing vapor to cover about 3,000 cubic feet to decontaminate bio-organisms in small business offices, medical rooms, work areas and industrial areas. If you are comparing hand sprayers and electro-sprayers to the CRF2-S, how much fog volume does the other fog generator produce and how big are sprayer liquid droplets, compared to the 10 micron vapor droplets of the CRF2-S? The CRF2-S provides constant fog volume and provides a 10 foot, power on/off remote cable. The CRF2-S would be used in bio-decontamination of small medical rooms, homes, business offices, police vehicles, ambulances, EMT vans, etc.
CRF2 - Click here for Cleanroom Fogger Video
Sanitizing Areas for Your Employees, or as a SERVICE to Your Customers
The CRF2-S produces a visible aerosol fog at about 10 micron droplet diameter, which is the right size of droplet to float in the air. The droplets exit at a constant fan speed. As the aerosol sterilant is pushed into the air, it begins to evaporate to a vapor at an exponential rate, which further accelerates the sterilant into all areas up to 3,000 cubic feet (87 cubic meters per cycle, killing spores, fungus, envelope viruses, molds, fungus, etc. The CRF2-S can be directly controlled or operated via a 10 foot remote power cable.
Compare CRF4-S and CRF2-S and DF2S Dry Foggers
(Details)
| Product Model | CRF4-S Decontaminating Fogger | CRF2-S Decontaminating Fogger | DF2S Decontaminating Dry Fogger |
| FOG Minutes | ~ 45 minutes | ~ 50 minutes | ~ 90 minutes |
| FOG, Cubic Meters/Min. | ~ 1.25 Cubic Meters/Min., visible | ~ 0.26 Cubic Meters/Min., visible | ~ 11.1 Cubic Meters/Min., not visible |
| Total Sterilant Vapor Volume @ 1 Cycle | ~ 10,000 cubic feet (285 cubic meters) per cycle. Refill and Restart as needed. | ~ 3,000 cubic feet (57 cubic meters) per cycle. Refill and Restart as needed. | ~ 35,000 cubic feet (1000 cubic meters) / cycle. Refill and Restart as needed. |
| Typical volume of sterilant used per cycle |
3.325 liters of H2O2 (@ 35% mixture) in 6.175 liters distilled water, total 9.5 liters liquid fill | 1.323 liters of H2O2 (@ 35% mixture) in 2.427 liters distilled water, total 3.78 liters liquid fill | 1.54 liters Minncare (@ 7% mixture) in 20.46 liters purified water, total 22 liters liquid fill. |
| Aerosol Fog Droplet size | ~ 8 microns | ~ 9-10 microns | ~ 7.5 microns |
| Typical Sterilant Used |
H2O2, Hydrogen Peroxide | H2O2, Hydrogen Peroxide | Minncare EPA Reg. NO.: 52252-4; EPA Est. NO.: 52252-MN-01 |
| Adjustable Airflow Velocity and Fog Volume |
Yes, thru touch pad and wireless remote control, as well as remote On/Off using Wireless | No airflow control, constant fog volume output | Constant fog volume output, controlled by air compressor, (dry air compressor recommended) |
| Fogger Technology | Ultrasonic creates sterilant fog @ 8 micron droplet which exponentially evaporates to a 10,000 cubic foot sterilant vapor | Ultrasonic creates sterilant fog @ 9-10 micron droplet which exponentially evaporates to a 3000 cubic foot sterilant vapor | Aerosol + Evaporation creates sterilant fog, which evaporates to sterilant vapor |
| Water Used | Distilled water is ideal or De-ionized Water, WFI water or sterile water. Tap Water should not be used due to chlorine in tap water. | Distilled water is ideal or De-ionized Water, WFI water or sterile water. Tap Water should not be used due to chlorine in tap water. | Distilled water is ideal or De-ionized Water, WFI water or sterile water. Tap Water should not be used due to chlorine in tap water. |
| Where used |
Medium sized office areas, medical rooms, hospital rooms, work areas | Small office areas, medical rooms, hospital rooms, work areas | Large office areas, medical rooms, hospital rooms, work areas, warehouses |
| Autoclavable | No | No | Yes, Autoclavable |
| Compatible Guidelines | ISO 14644-3, USP 797 | ISO 14644-3, USP 797 | ISO 14644-3, USP 797 |
| Compatible Guidelines | Check with Local/State Health for any compliance requirements | Check with Local/State Health for any compliance requirements | Check with Local/State Health for any compliance requirements |
| Dry Compressor Requirements |
No, CRF4-S includes onboard fan control and volume control | No, CRF2-S includes constant fan output | DF2S requires external Dry Air Compressor at 70-100 psi |
| Total Deionized/Sterile Water and Sterilant Volume | 9.5 liters | 3.75 liters | 22 liters |
| Typical Sterilant Concentration |
H2O2 is purchased from your local chemical supplier and mixed from 3.5% to 35% solution in distilled / purified water | H2O2 is purchased from your local chemical supplier and mixed from 3.5% to 35% solution in distilled / purified water | Minncare Sterilant is mixed from 3 % to 10 % in purified water |
| Operator Control | Touch pad control of fog volume & airflow | Power Switch, no fog controls | Operated by separate Dry Air Compressor |
| Remote Control | Wireless Remote control of fog volume & airflow | Remote Cable Control, 10 feet | No Wireless Remote Control of fog |
| Handling | Carry Handles (top and front) | Carry Handle (top) | Carry Handle |
| Enclosure | 316L Stainless Steel, electro-polish | Polyethylene Enclosure | 316L Stainless Steel, electro-polish |
| Power VAC | 120, 220, 100 VAC | 120, 220 VAC | 120, 220, 100 VAC to Compressor only |
| Full Weight | ~ 65 lbs | ~ 20 lbs | ~ 110 lbs |
| Accessories | 12 Accessories quoted/suggested | 8 Accessories quoted/suggested | 12 Accessories quoted/suggested |
Sanitizing Fogger, Decontaminating Fogger
The CRF2-S is a portable sanitizing and decontamination fogger is designed with a polyethylene enclosure, which is resistant to most environments. The CRF2-S Fogger produces a 10 micron fog which quickly evaporates to spread into an area of interest, allowing the sterilant to come into contact with open surfaces of bio-organisms to kill unwanted viruses, envelope viruses, spores, molds, fungus. CRF2-S ships in a rolling, carry case with handle and wheels to protect the sanitizing fogger during transit and storage, when moving from location to location. Hydrogen Peroxide is used in the CRF2-S most often as a sterilant. H2O2 is found in nearly every home and is quite effective against unwanted bio-organisms. Hydrogen peroxide can be purchased at your local pharmacy, along with Distilled water. A Drain and Dry kit is included in CRF2-S package to easily drain the sterilant after use, and then to dry CRF2-S out before storing the fogger in the rolling carry case.
CRF2-S Technology
CRF2 uses 9 ultrasonic piezo devices to generate a pure visible sterilant fog of 0.26 cubic meters / minute, which exponentially evaporates to a sterilant vapor covering up to 3000 cubic feet, allowing the sterilant to come into contact with bio-organisms in that 3000 cubic foot area, in the air and on available surfaces.
SANITIZING FOGGER INFORMATION
The CRF2-S can be turned on or off at will, and refilled with Deionized water, Sterile Water or WFI Water as needed. The fog volume is constant. The only maintenance is to drain water and to air dry the water cavity immediately after each fog study.
In order to create larger volumes of fog, 9 ultrasonic devices are used, which vibrate at high frequencies, generating high volumes of vapor droplets at a diameter of 10 microns. The CRF2-S produces about 0.26 cubic meters of visible sanitizing fog, which evaporates to about 3000 cubic feet if the unit is run for a typical 50 minute cycle.
The transducer life is ~3,000 hours. To protect the transducers from damage there is a level sensor that will interrupt the input voltage to the transducer module, should the water level drop to a low level. This ensures long life and reliability.
Notes:
- The fog generated by this device contains microscopic droplets of DI water. AVOID USING IN IMMEDIATE VICINITY OF ELECTRICAL APPLIANCES, WATER SENSITIVE PRODUCTS AND EQUIPMENT.
- The fan will operate with no water in the reservoir with the power switch in the ON position. This will aid in drying when the chamber is drained.
- Ensure the drain plug is snug tight.
- The CRF2 is intended to be used on a flat surface, on its feet, sitting on the floor, table, or a flat trolley cart. Tipping the fogger with water in the reservoir will damage the fogger. DO NOT OVERFILL OR TIP THE CRF2-S FOGGER DURING OPERATION.
CRF2-s Sterilizing Fogger From Applied Physics Inc.
