Sample Concentrator

$0.00

Introduction：
The sample concentrator employs a sweeping needle capture technique, which allows for simultaneous temperature-controlled heating of the samples. Utilizing inert gases such as nitrogen, it rapidly, controllably, and continuously blows onto the sample surface, achieving rapid anaerobic concentration of the sample volume. This method is characterized by its time-saving, convenient, and precise nature and is extensively applied in fields such as pesticide residue analysis, pharmaceutical testing, environmental analysis, bio-analysis, commodity inspection, and food and beverage testing.

ELGA CENTRA · CENTRAL DISTRIBUTION

Size purification, storage and loop delivery as one system

CENTRA is selected for multi-point laboratory distribution. The quote should define required water grade, daily production, peak simultaneous demand, reservoir strategy, loop flow, distribution distance, sanitization approach and future expansion.

Multiple points of usePurification + storage + distributionLoop-flow requirement mattersPlan for sanitization + expansion
CENTRA application guideCompare systemsReview the loop
SKU: AP-Sample-Concentrator Categories: , Catalog relationship: Available Through Applied Physics
Related Applied Physics resources

Continue through the Medical portfolio

Use these technical and portfolio pages to compare applications and related equipment. To keep this exact product attached to an RFQ, use the product’s existing Request a Quote or Add To Order control.

Applied Physics Medical Clinical & Sterile Processing

Description

Sample Concentrator

Features：

1. The distribution chamber’s gas channels can be combined or used individually, with independent control for each.The height of the distribution chamber can be adjusted as needed.

2. Individual gas flow adjustment for each channel, addressing the issue of inconsistent flow rates in traditional nitrogen blowers, and featuring a flexible self-balancing lifting system.

3. Digital temperature controller with dual digital display, using PID technology for regulation and capable of high-temperature alarm.

4. All solvent-contact parts are made of 316 stainless steel for durability and ease of cleaning.

5. The entire unit can be used inside a fume hood.

6. Optional gas flow meters and pressure regulators are available for each model.

7. Standard test tube rack is φ16.5mm; the hole diameter and arrangement pattern are customizable.



Technical Parameters：

Model

BK-SC12

BK-SC24

BK-SC36

BK-SC48

Heating Method

Water bath

Max Number of Samples

12

24

36

48

Temp. Control Range

RT~100℃

Temp. Accuracy

±1℃

Heating Time

20~25min(From 25℃ to 100℃)

Max Gas Usage

15L/min

Consumption

600W

Timing Range

1~999min

Needle Length

150mm

Needle Diameter

1mm

Power Supply

220V, 50/60Hz

External Size(W*D*H)

340*200*460mm

Packing Size(W*D*H)

500*280*410mm

Net Weight

7kg

7.5kg

7.5kg

8kg

Gross Weight

9kg

9.5kg

9.5kg

10kg

Additional information

Model

BK-SC12, BK-SC24, BK-SC36, BK-SC48
