Vacuum Seed Counting& Placing Instrument

Description

Vacuum Seed Counting& Placing Instrument

Features:

1. Used for seed counting, suction and placing in the course of seed germination.

2. Made up of main machine, suction tube and suction head.

3. With control button to control the suction power according to seed size.

4. With 5 different seed suction heads, its size and specification match with Petri dish, meet needs of different seed germination.

Technical Parameters:

Model

BK-SCP2000

Temperature

≤40°C

Power

1200W at 220V 50Hz

Power Supply

Standard: 220V, 50Hz; Optional: 110V, 60Hz

Suction Plate

5pcs

Suction Size

12*8.8(100 holes, for corn, 1pc); 16.7*12(1pc); 10.3*10.3(100 holes, 2pcs), Φ8(100 holes/pc)

Packing Size

600*350*260mm

Gross Weight

14kg

Sort

Sucked Seed

Sucked Amount

Figure

Incubation Utensil

A

Corn/Bean/Cotton seed/Big Granule

Vegetable Seed

25

Rectangle

PL18 PH18

B

Rice/Wheat/Barley/Sorghum

100

Rectangle

PL18 PH18

C

Rice/Wheat/Barley/Sorghum

100

Square

PL12 PH12

D

Rape seed and middle or small granule vegetable seed

100

Square

PL12 PH12

E

Small granule vegetable seed

100

Roundness

φ9mm glass utensil
