Description
Low-temperature storage: The -30 degree temperature range is ideal for many items in the medical field that require specialized refrigeration conditions. These items include vaccines, blood products, and other biological samples. The medical refrigeration unit can provide a stable and consistent low-temperature environment, ensuring the quality and effectiveness of these items.
Technical Parameters:
|
Model |
BDF-30V368D |
BDF-30V528D |
|||
|
Capacity |
368L |
528L |
|||
|
Temp. Range |
-10~-30℃ |
||||
|
Temp. Accuracy |
0.1℃ |
||||
|
Temp. Uniformity |
≤3℃ |
||||
|
Temp. Stability |
≤3℃ |
||||
|
Recovery Time(Recover to -22℃ in an ambient temp. of 25℃) |
≤15min |
||||
|
Cooling Time(Cool down to -25℃ in an ambient temp. of 25℃) |
≤1.5h |
||||
|
Control System |
Microprocessor control |
||||
|
Display |
LED display |
||||
|
Alarm |
High and low temperature alarm, thermostat fault alarm, door switch alarm, power failure alarm(72h) |
||||
|
Refrigeration Type |
Direct-cooling |
||||
|
Refrigerant |
Upper Chamber: R290, 50g Lower Chamber: R290, 50g |
Upper Chamber: R290, 62g Lower Chamber: R290, 62g |
|||
|
Compressor |
International famous brand compressor/2 |
||||
|
Condenser&Evaporator |
Wire-on-tube Bundy tube condenser; built-in coil type copper tube evaporator |
||||
|
Defrost |
Manual defrost |
||||
|
Construction |
Polyurethane cyclopentane foam |
||||
|
Material |
Internal Material |
304 stainless steel |
|||
|
External Material |
Sprayed steel plate |
||||
|
Door |
Outer door: cyclopentane integral foam outer door*2 Inner door: optional |
||||
|
Consumption |
718W |
821W |
|||
|
Power Supply |
AC220V, 50Hz(Standard); 220V, 60Hz, 110V, 60Hz(Optional, external transformer) |
||||
|
Casters |
Yes |
||||
|
Shelf |
4 |
||||
|
Standard Accessory |
Test hole*2, USB interface |
||||
|
Optional Accessory |
RS485 interface, inner door, temperature recorder |
||||
|
Internal Size(W*D*H) |
Upper chamber |
580*575*563mm |
720*649*563mm |
||
|
Lower chamber |
|||||
|
External Size(W*D*H) |
750*736*1884mm |
890*810*1884mm |
|||
|
Package Size(W*D*H) |
890*880*2100mm |
1030*950*2100mm |
|||
|
Net Weight |
153kg |
177kg |
|||
|
Gross Weight |
168kg |
200kg |
|||
