OI Automatic Gel Imaging and Analysis System is a highly integrated and fully automated gel imaging system, system interface is simple and practical, the main interface has shooting button and time control to guide the user, it is very easy to operate, no need for complex and tedious debug, it is your best choice.
$0.00
Automatic Gel Imaging and Analysis System BK-AG1000 BK-AG200 (Customized)
Product Features:
High resolution CCD camera, high sensitivity, high resolution, with automatic focus and high performance lens, specialized filter for nucleic acid dye.
Specialized overlay glue cutting filter, compared with the traditional one, it has many advantages, easy to operate, can prevent UV and blue light damage, no need to operate in dark room, work very well under strong light condition. The white light sample plate is used for SDS PAGE glue samples shooting.
Product Application:
It can be used to do nucleic acid test for various fluorescent dyes, such as EB, SYBR Gold, SYBR Green, SYBR Safe, Gel Red, Gel Green, Texas Red, Fluorescein marked DNA/RNA.
Technical Parameters:
Mode
BK-AG1000
BK-AG2000
Pixel
2592×1944(5.03MP)
3000×4000(12MP)
Exposure Time
1ms~3000ms
1ms~60min
QE Value
High QE: >65%
High QE: >75%
Binning
1×1
1×1, 2×2, 4×4
Bit Depth
16 bit(0-65535)
16 bit(0-65535)
OD
≥4.8OD
≥4.8OD
Lens
F=1.4, 20 million auto focus lens
F=1.4, 20 million auto focus lens
Light Source
Trans-UV 302nm; Epi-White LED; Trans-White UV to white sample plate; Epi-UV 254nm, 302nm, 365nm for option
Trans-UV 302nm; Epi-White LED; Trans-White UV to white sample plate; Epi-UV 254nm, 302nm, 365nm for option
Filters
590nm, Others for option
590nm, Others for option
UV Area
21×21cm
21×21cm
Timing Off
1~60 mins
1~60 mins
| Model | BK-AG1000, BK-AG2000 |
|---|
