Solid and Liquid Densimeter BK-DME300D BK-DME600D

Description

Solid and Liquid Densimeter BK-DME300D BK-DME600D

Features:

1. Automatic zero tracking, buzzer warning, and overload warning.

2. Function of solution compensation: necessary if liquid other than water is used as a medium for measuring.

3. Actual water temperature compensation.

4. RS-232C included.

Technical Parameters:

Model

BK-DME300D

BK-DME600D

Capacity

0.005~300g

0.005~600g

Density Resolution

0.001g/cm3

Density Range

0.001~99.999g/cm3

Measuring Time

About 5s

Solid Mode

Measuring Principle

Archimedes principle general solid test method

Specific Gravity Measurable Frame

Unibody injection forming professional specific gravity measurement frame.

Measuring Tank

Unibody injection forming transparent professional measuring tank.

Size: 153*107*93mm(L*W*H)

Mixed Material

Percentage

Function

Introduction

Automatically read the percentage of the main material in composite which consist of two materials

Setting

Freely set the density value of main material and subordinate material

Display

Density value, percentage of main material

Liquid

Mode

Measuring Principle

Archimedes principle displacement method

Weight Value Data

Storage

1 group

Specific Gravity

Measuring Frame

Stainless steel specific gravity measuring frame

Memory Mode

Dynamic memory

Result Display

Density value

Result Testing Method

Distilled water testing

Calibration Mode

Auto correction, auto detection

Standard Accessories

Common Use: Tweezer, thermometer, 100G weight, windshield, power transformer.

Solid Use: Tank, testing board, a set of particle measuring assembly, a set of floating body measuring assembly.

Liquid Use: Measuring plate, measuring frame, DE-20A standard liquid measuring assembly.

Optional Accessories

DE-40 printer, DE-20B anti corrosive liquid measuring assembly

Power Supply

AC100~240V, 50/60Hz

External Size(W*D*H)

195*230*197mm

Package Size(W*D*H)

440*180*345mm

Net Weight

1.78kg

1.79kg

Gross Weight

4.5kg
