Surgical Shadowless Lamp BK-LED500 BK-LED700 BK-LED500/700

Description

Surgical Shadowless Lamp BK-LED500 BK-LED700 BK-LED500/700

Features:

1. Cold Light Source Technology

Advanced LED cold light source with zero UV/IR emission. Temperature rise ≤1°C in surgical areas, 80,000+ hours lifespan, energy-efficient and eco-friendly.

2. Intelligent Optical Adjustment

Multi-level adjustable color temperature (3000K-6700K). High CRI (Color Rendering Index) enhances tissue contrast visualization. Uniform light column ensures deep-cavity illumination while reducing visual fatigue.

3. Precision Control System

LCD touch interface with one-touch endoscopic mode. Preset memory for customized parameters. Multi-channel independent control ensures uninterrupted illumination during single-LED failure.

4. Sterile & Purification-Optimized Design

Seamless aerodynamic housing with aluminum alloy heat dissipation. Silicone-sealed dustproof construction complies with laminar airflow standards. Easy-to-clean surfaces support aseptic protocols.

5. Articulated Suspension System

Dual curved arms + multi-joint linkage. 340° horizontal rotation, 90° vertical range, and precision positioning. 50,000-cycle endurance tested for multi-angle adaptability in complex procedures.

6. Autoclavable Focus Handle

Stepless focus adjustment with detachable high-temperature-resistant handle (≤160°C autoclave compatible), enabling rapid intraoperative sterilization.

7. Premium Components

MEAN WELL power supplies (Taiwan-based). Swiss-made antibacterial and flame-retardant coating (EU ROHS-certified) ensures safety and durability.

8. Base

Rigorously validated via mechanical simulation, the “M”-shaped base integrates four-wheel support, weighted steel plates, and silent wear-resistant casters—ensuring stability, easy maneuverability, and secure positioning anywhere.

Technical Parameters:

Model

BK-LED500L

BK-LED700L

Number of LEDs

48

80

Center Illuminance(LUX at 1M)

40000~160000 (Adjustable)

Color Temperature(K)

3000K ≤ Tc ≤ 6700K (Adjustable)

Color Rendering Index(Ra)

85 ≤ Ra ≤ 100

Spot Diameter(mm)

≥120

Spot Distribution Diameter(mm)

≥60

Light Column Depth(mm)

≥800

Irradiance(W/m²)

≤900

Temp. Rise at Surgeon’s Head(°C)

≤1

Temp. Rise in Surgical Field(°C)

≤2

Average Lamp Life(h)

≥80000

Lamp Power

1W

Power Supply

AC100~240V,50/60Hz

Consumption

200VA

Packing Size(W*D*H)

765*590*215mm;

1060*220*200mm;

840*860*300mm

765*590*215mm;

1060*220*200mm;

1035*965*305mm

Net Weight

74kg

77kg

Gross Weight

48kg;19kg;14kg

48kg;19kg;19kg
