Description
Applied Physics Semiconductor offers a complete lineup of standard SMT nozzles, fully compatible with JUKI pick and place machines. Our high-precision nozzles—502, 503, 504, 505, 506, and 507—are engineered for reliability, accuracy, and consistent placement, and are among the most popular sizes in the industry.
Product Table: Standard SMT Nozzle Sizes & Applications
| Nozzle Model |
Compatible Component Sizes |
Recommended Use |
Compatible Machines |
| 502 |
0402 |
Smallest passives |
JUKI 2050, JUKI 2060, others |
| 503 |
0603, 0805 |
Small-to-medium passives |
JUKI 2050, JUKI 2060, others |
| 504 |
0805, 1206 |
Medium passives |
JUKI 2050, JUKI 2060, others |
| 505 |
3535 LED |
LED components |
JUKI 2050, JUKI 2060, others |
| 506 |
Various |
General purpose |
JUKI 2050, JUKI 2060, others |
| 507 |
Various |
General purpose |
JUKI 2050, JUKI 2060, others |
Key Features
- Precision-Fit: Designed for seamless operation with JUKI 2050, JUKI 2060, and compatible SMT machines.
- Versatile Sizing: Six industry-standard nozzle types to cover a broad range of SMD and LED components.
- Reliable Performance: Manufactured to stringent tolerances for excellent placement accuracy in high-speed assembly.
- Durable Materials: Built for long service life and consistent operation in demanding production environments.
How to Choose the Right Nozzle
- 502 Nozzle: Best for 0402 components.
- 503 Nozzle: Ideal for 0603 and 0805 components.
- 504 Nozzle: Suitable for 0805 and 1206 components.
- 505 Nozzle: Designed for 3535 LED placement.
- 506/507 Nozzles: Flexible for various component types.
Why Choose Applied Physics Semiconductor?
- US-Based Sales & Support: Fast shipping and technical assistance from our North American team.
- OEM-Quality, Direct from Source: Manufactured to our specifications for superior reliability.
- Comprehensive Warranty: 1-year warranty and lifetime technical support.
- Complete Solutions: Tools and manuals included; one-on-one after-sales service available.
