The biological microscope is a kind of precision optical instrument used to observe biological sections, biological cells, bacteria, tissue cultures, fluid precipitation and other objects. It is widely used in medical and health units, universities, research institutes and other fields, especially in cytology, parasitology, oncology, immunology, genetic engineering, industrial microbiology and botany has important applications.
$0.00
Technical Parameters:
| Specification | Model | ||||||
| XS-208A | XS-208B | XS-208C | XS-208AP | XS-208BP | XS-208AB | ||
| Observation Head | 45° tilt sliding binocular observation head | √ | |||||
| 45° tilt sliding trinocular observation head | √ | ||||||
| Hinged 30° binocular observation head | √ | √ | |||||
| Hinged 30° trinocular observation head | √ | √ | |||||
| Nosepiece | Multi-roller four-aperture objective lens converter | √ | √ | √ | √ | √ | √ |
| Eyepiece | Wide-angle plane eyepiece: WF10X/18mm | √ | √ | √ | √ | √ | √ |
| Objective Lens | Achromatic 4X, 10X, 40X(spring), 100X(spring, oil) | √ | √ | √ | |||
| Plan achromat 4X, 10X, 40X(spring), 100X(spring, oil) | √ | √ | |||||
| Infinity plan achromat 4X, 10X, 40X(spring), 100X(spring, oil) | √ | ||||||
| Stage | Double-layer mechanical platform 135*140mm | √ | √ | √ | √ | √ | √ |
| Condenser | ABBE NA1.25 condenser with variable aperture and filters, rack and pinion adjustment | √ | √ | √ | √ | √ | √ |
| Illumination | Built-in lighting | √ | √ | √ | √ | √ | √ |
| Power Supply | AC100~240V, 50/60Hz | √ | √ | √ | √ | √ | √ |
| Optional Accessories | Darkfield condenser, phase contrast accessories | √ | √ | √ | √ | √ | √ |
| Package | Foam carton | √ | √ | √ | √ | √ | √ |
| Packing Size | 250*360*460mm | √ | √ | √ | √ | √ | √ |
| Gross Weight | 8kg | √ | √ | √ | √ | √ | √ |
| Model | XS-208A, XS-208B, XS-208C, XS-208AP, XS-208BP, XS-208AB |
|---|
